MTL 8123- PL-QU Isolated Discrete Input Module

Product Description

The MTL 8123-PI-QU is a dual-channel pulse and quadrature input module designed for high-precision frequency and acceleration measurements in industrial automation systems. It supports NAMUR sensors and configurable input types, suitable for applications in safe and hazardous areas.

Technical Specifications

• Model: 8123-PI-QU

• Manufacturer: MTL Instruments (Eaton)

• Module Type: Pulse/Quadrature Input Module

• Channels: 2 independent channels

• Input Types:

• NAMUR proximity sensors

• Current pulse inputs

• Voltage pulse inputs

• Switch inputs

• Frequency Range:

• Up to 50 kHz

• 12.5 kHz in quadrature mode

• Accuracy: ±0.05% of span at 25°C

• Temperature Stability: 0.005% per °C

• Current Input:

• Signal: 20 mA (max.)

• Thresholds: Configurable in 8 levels

• Input Impedance: 25 Ω

• Open Circuit Current: <0.5 mA

• Short Circuit Current: >21.5 mA

• Voltage Input:

• Signal: 0–24 V DC (50 V max.)

• Thresholds: Configurable in 8 levels

• Input Impedance: >10 kΩ

• Switching Hysteresis: 100 mV

• Switch Input: Voltage Range: 0–10 V DC

• Outputs:

• Type: Open-collector for separately powered devices

• Number of Channels: 2

• OFF State Voltage: 30 V (max.)

• OFF State Leakage Current: 10 μA (max.)

• ON State Voltage Drop: <1.0 V at 50 mA

• ON State Current: 100 mA

• Retransmission Bandwidth: 1–2000 Hz

• Isolation:

• Channel to Railbus: 100 V AC

• Between Input Channels: None

• Between Output Channels: 30 V AC

• Response Times: Signal change to Railbus availability: ≤25 ms

• Power Supplies:

• Railbus Current (both channels at 22 mA): 300 mA max

• Bussed Field Power: 20 mA at 24 ±10% V DC

• Power Dissipation (both channels at 22 mA): 2.8 W max

• Mechanical:

• Module Key Code: F2

• Module Width: 42 mm

• Weight: 260 g

Other Attributes

• Country of Origin: France
  Lead Time:&nbsp;In Stock, 2 Working Days
