Product DescriptionTechnical Specifications
| Specification Category | Details |
|---|---|
| Module Name | 3500/94M VGA Display Unit |
| Power Consumption | 4.6 watts max |
| Network Interface | High-speed network to monitor status, data, and values |
| RS232 Port (I/O) | Touch controller data |
| VGA Port (I/O) | Analog red, green, blue, and sync signals to the display |
| Front Port | 24 Vdc power out, VGA signal out, touch commands in |
| LED Indicators | OK LED: Indicates proper operation TX/RX LED: Indicates module communication |
| Operating Temperature | -20°C to +65°C (-4°F to +149°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 95%, non-condensing |
| EMC Compliance | EN 61000-6-2, EN 61000-6-4 |
| Electrical Safety | CSA C22.2 61010-1, UL EN 61010-1 |
| Directives | 2014/30/EU, 2014/35/EU, RoHS 2011/65/EU |
| FCC Compliance | Part 15, subject to interference acceptance rules |
FAQ
Q: What components are included in the 3500/94 VGA Display Monitor system?
A: The system comprises the 3500/94 VGA module, its I/O card, and the VGA display monitor.
Q: How far can the VGA display monitor be mounted from the rack?
A: The display monitor can be mounted up to 8 meters (25 feet) from the rack using standard cabling.
Q: Can the display monitor show data from multiple racks?
A: Yes, with the optional Display Router Box, the monitor can display data from up to four separate 3500 racks.
Q: What is the power requirement for the display monitor?
A: The display monitor requires a +24 VDC power supply with a maximum consumption of 4.6 watts.
