Product DescriptionTechnical Specifications
| Category | Specification |
|---|---|
| Inputs | Accepts 1 to 6 RTD or TC transducer signals |
| Input Impedance | 10 MΩ for each lead input |
| Power Consumption | 3500/60: 7 W nominal3500/61: 9 W nominal |
| Thermocouple Types | Type E: -100°C to +1000°C (-148°F to +1832°F)Type J: -18°C to +760°C (0°F to +1400°F)Type K: -18°C to +1370°C (0°F to +2498°F)Type T: -160°C to +400°C (-256°F to +752°F) |
| RTD Types | 100Ω 3-wire & 4-wire platinum (α=0.00385): -200°C to +850°C (-328°F to +1562°F)100Ω 3-wire & 4-wire platinum (α=0.00392): -200°C to +700°C (-328°F to +1292°F)120Ω 3-wire & 4-wire nickel: -80°C to +260°C (-112°F to +500°F)10Ω 3-wire & 4-wire copper: -100°C to +260°C (-148°F to +500°F) |
| RTD with External Barriers | Platinum 0.00385: -50°C to +850°C (-122°F to +1562°F)Platinum 0.00392: -50°C to +260°C (-122°F to +500°F)Nickel: -50°C to +260°C (-122°F to +500°F)Copper: -50°C to +260°C (-122°F to +500°F) |
| I/O Module Type | RTD/TC Non-isolated I/O Module |
| System Isolation | 500 VDC |
| Channel-to-Channel Isolation | 250 VDC |
| Internal Terminations | Provided on module |
| Agency Approval | CSA/NRTL/C (Class 1, Div 2) |
| Notes | Isolation required only in fault scenarios; voltages not present during normal operation |
FAQ
Q: What is the input type for the 3500/60-01-02 module?
A: The module accepts a 100Ω platinum RTD input for precise temperature measurements.
Q: What is the measurement range of the 3500/60-01-02 module?
A: It measures temperatures from -200°C to +850°C (-328°F to +1562°F), covering a broad spectrum of industrial applications.
Q: What is the accuracy of the 3500/60-01-02 module?
A: The module offers an accuracy of ±1°C at 25°C (±1.8°F at 77°F), ensuring reliable temperature readings.
Q: What is the power supply requirement for the 3500/60-01-02 module?
A: The module operates on a 24 VDC power supply, compatible with standard industrial power sources.
Q: What is the operating temperature range of the 3500/60-01-02 module?
A: It functions effectively within an operating temperature range of -40°C to +70°C (-40°F to +158°F).
Q: What are the dimensions of the 3500/60-01-02 module?
A: The module measures 120.7 mm x 50.8 mm x 251.5 mm, fitting into a half-height slot in the 3500 Series rack.
