Home » BentlyNevada 3500/20-01-02-00 125744-02 125768-01 Rack Interface Module
Bently Nevada

BentlyNevada 3500/20-01-02-00 125744-02 125768-01 Rack Interface Module

SKU: 3500/20-01-02-00 125744-02 125768-01
(0)

Technical specifications

  • Manufacturer: Bently Nevada

  • Condition：New with Original Package

  • Product Type: Rack Interface Module

  • Country of Origin: USA

  • Payment:T/T, Western Union

  • Shipping port: Xiamen

  • Warranty: 12 months

By submitting a request for this item, you confirm that you have reviewed and accepted our Terms & Conditions. Please note that all transactions will be processed offline.

100% Original and Authentic
100% Brand New, Ready to ship
Support Refund, 7X24h Service
1-Year Warranty on All Products

Ask an expert

Chat Email +8618030205725

Help us reach more people! Share this product with your network and show your support!

Product Description

The Bently Nevada 3500/20-01-02-00 125744-02 125768-01 Rack Interface Module provides reliable system communication between 3500 series monitoring modules. It ensures seamless data transmission, robust signal integrity, and secure rack-level integration. This module simplifies rack wiring while maintaining high operational reliability in industrial environments.

Technical Specifications


Specification Details
Model 3500/20-01-02-00 125744-02 125768-01
Manufacturer Bently Nevada (GE)
Module Type Rack Interface Module (RIM)
I/O Module Type RS232/RS422 Serial Interface
Power Consumption 4.75 Watts typical
Data Communication RS232 serial communications, RS422 optional, internal modem supported
Baud Rate 38.4 k baud maximum (auto baud capable), 14.4 k baud for modem
Cable Length Maximum 30 meters (100 feet)
Front Panel LEDs OK, TX/RX, TM, CONFIG OK
OK Relay 5A @ 24 Vdc / 120 Vac, 120 Watts / 600 VA, Normally Energized, user-selectable
Controls Rack Reset button, Address switch, Configuration Keylock
I/O Module System Contacts Trip Multiply, Alarm Inhibit, Rack Reset
Operating Temperature -30°C to +65°C (-22°F to +149°F)
Storage Temperature -40°C to +85°C (-40°F to +185°F)
Agency Approvals None



FAQ

Q1: What type of signals does the 3500/20 Rack Interface Module support?
A1: The 3500/20-01-02-00 supports both digital and analog signals across 3500 series modules.

Q2: Does this module have internal terminations?
A2: Yes, internal terminations simplify rack installation and reduce wiring errors.

Q3: What is the module’s typical power consumption?
A3: The 3500/20 125744-02 125768-01 consumes approximately 5 Watts under normal operation.

Q4: Is it suitable for hazardous areas?
A4: Yes, it is CSA/NRTL/C Class 1, Div 2 certified for safe industrial usage.

Q5: How are operational and communication statuses indicated?
A5: The front panel includes OK and TX/RX LEDs for monitoring module and communication status.



Other Attributes

  • Series: 24765 and 135613 Case Expansion Transducer Systems
  • Country of Origin: USA
  • Lead Time: In Stock, 2 Working Days
