Bachmann WT305E LX700/DD256/CF512MB Operator Interface

Product Description

The Bachmann WT305E LX700/DD256/CF512MB is an industrial operator interface with an integrated keypad, designed for local operator interaction with automation equipment. Its configuration identifies the LX700 system, DD256 memory designation, and CF512MB storage designation. The unit uses a 24 VDC power supply and provides Ethernet, USB, and serial communication interfaces for connection to compatible control and peripheral equipment.

Technical Specifications

Configuration and Communication Interfaces

The WT305E combines a local operator keypad with computing and communication functions. The LX700/DD256/CF512MB configuration identifies the system and memory/storage designations for this unit. Confirm these identifiers against the equipment nameplate when replacing an installed terminal.

The communication interfaces include Ethernet, USB 2.0, and a serial port supporting RS232, RS422, or RS485. The selected serial standard and wiring must match the connected device. Do not assume that all three serial standards operate simultaneously.

Power and Installation Conditions

The specified supply range is 18-36 VDC, with a nominal supply voltage of 24 VDC and a listed power rating of 45 W. Select a power supply that meets the terminal's electrical requirements and allows for the specified load.

The listed operating temperature range is 0 to 50 deg C. The fanless cooling design eliminates the need for an internal cooling fan, while the specified dimensions and weight help technicians assess panel space and mounting requirements.

Frequently Asked Questions

Q: How can I identify the correct WT305E replacement?

A: Check the complete model designation, WT305E LX700/DD256/CF512MB, against the installed unit. Also verify the power rating, communication interfaces, and keypad configuration before ordering a replacement.

Q: What power supply does the WT305E require?

A: The specified supply is 24 VDC, with an acceptable range of 18-36 VDC and a listed power rating of 45 W. Verify the power supply capacity and connection requirements before installation.

Q: Which communication interfaces does this operator interface provide?

A: The listed interfaces are one 10/100 Mbps Ethernet port, two USB 2.0 ports, and one serial port supporting RS232, RS422, or RS485. Confirm the required interface standard and connection details for the intended application.
