991-06-70-01-00 991 Bently Nevada 3300 System Thrust Transmitter 100% New In Stock

991-06-70-01-00 991 Bently Nevada 3300 System Thrust Transmitter 100% New In Stock


  • Manufacturer: Bently Nevada

  • Part Number: 991-06-70-01-00

  • Condition:New with Original Package

  • Product Type: Thrust Transmitter

  • Payment:T/T, Western Union

  • Shipping port: Xiamen

  • Warranty: 12 months


Product Description

The 991 Thrust Transmitter is intended primarily for the original equipment
manufacturers (OEMs) of centrifugal air compressors or small pumps, motors, or fans who prefer to provide a simple 4 to 20 mA proportional axial displacement (thrust) signal as the input to their machinery control system. The transmitter is a 2-wire, loop-powered device that accepts input from our 3300 NSv* proximity probe and its matching extension cable (available in 5 m and 7 m system length options). The transmitter conditions the signal into appropriate engineering units proportional to the shaft’s axial position1, and provides it as a 4 to 20 mA industry-standard signal for input to the control system where machinery protection alarming and logic occurs2. The 991 transmitter provides the following notable features:
  • Integrated Proximitor* Sensor requires no external unit
  • Non-isolated “PROX OUT " and "COM" terminals plus a coaxial connector provide a dynamic vibration and gap voltage signal output for diagnostics3.
  • Non-interacting zero and span potentiometers under the Transmitter label supports loop adjustment.
  • Test Input pin allows quick verification of loop signal output, using a variable DC voltage source as the input.
  • A Power-up Inhibit circuit eliminates signal errors due to line voltage transients
  • A Not OK/Signal Defeat circuit prevents high outputs or false alarms due to faulty proximity probe or loose connection.
  • Choice of DIN-rail clips or bulkhead mounting screws as standard option simplifies mounting.
  • Potted construction for high humidity (up to 100% condensing) environments.
  • Compatibility with 3300 NSv proximity probe allows transducer installation in small areas with minimal clearance, typical of centrifugal air compressors.



Other Attributes

  • Series: 3300 System
  • Country of Origin: USA
  • Lead Time: In Stock, 2 Working Days
