3500/05-01-03-01-00-01 Bently Nevada System Rack

Product Description

The Bently Nevada 3500/05-01-03-01-00-01, also cataloged as the 3500/05 System Rack, operates as a dedicated hardware chassis component for module mounting, power distribution, and inter-module communication within the Bently Nevada 3500 Machinery Protection System.

Hardware Specifications

Eddy-Current Monitoring and Rotor Dynamics Interface

The 3500/05 rack provides the physical mounting structure required for Bently Nevada 3500 monitoring modules that process vibration, position, speed, and mechanical condition signals. Therefore, the rack maintains the electrical and mechanical alignment required for continuous machinery protection configurations.

When combined with compatible proximity monitoring modules, the system supports eddy-current probe scaling functions, including accurate conversion of probe signals into displacement measurements. The rack architecture allows installed modules to maintain consistent signal paths for rotor dynamics analysis, including shaft vibration, axial position, and phase reference measurements.

The chassis arrangement also supports signal integrity practices used in rotating machinery monitoring systems. Proper module placement, grounding, and cable routing reduce electrical interference and support cross-talk suppression between monitoring channels.

Frequently Asked Questions

Q: Does the 3500/05-01-03-01-00-01 rack include monitoring modules or power supply modules?
A: No. The rack provides the chassis structure, module slots, and internal interconnection functions. Monitoring modules, power supplies, and Rack Interface Modules must be installed separately.

Q: Can the bulkhead mount version be installed without rear access?
A: Yes. The -03 bulkhead mount option supports installations where rear access is restricted. Wiring and I/O connections remain accessible from the front side of the rack.

Q: Does the rack determine the machinery protection measurement accuracy?
A: No. Measurement accuracy depends on the installed monitor modules, transducers, configuration parameters, and signal calibration. The rack provides mechanical support and communication infrastructure.

Field Installation Guidelines

• Install the rack inside a suitable enclosure or cabinet that provides mechanical protection and environmental control.
• Verify that the mounting structure supports the full rack assembly, including installed power supplies and monitoring modules.
• Maintain proper grounding between the rack chassis and the cabinet grounding system to reduce electrical noise.
• Route transducer cables separately from high-current power wiring to minimize electromagnetic interference.
• Confirm module slot assignments before installation to maintain correct system configuration.
• Inspect connector alignment before inserting monitor modules, Rack Interface Modules, or power supply assemblies.
• Verify cable shielding termination according to the site grounding standard and Bently Nevada installation requirements.

Other Attributes

• Series: 24765 and 135613 Case Expansion Transducer Systems
• Country of Origin: USA
• Lead Time: In Stock, 2 Working Days
