CC-E/STD 1SVR011705R2100 ABB Signal Converter Universal V/I / V/I Module

Configured for signal conditioning and electrical conversion in process signal interface layers, the ABB CC-E/STD (CC-E/STD Signal Converter) provides direct physical/electrical execution for universal V/I and V/I conversion between analog field signals and control system input/output terminals.

Technical Summary

The CC-E/STD is a universal signal converter designed for bidirectional analog conversion between voltage and current interfaces. It supports multiple standardized process signals including 0.5 V, 0-10 V, 0-20 mA, and 4-20 mA, with configurable input/output mapping. The unit operates from a wide AC control supply range of 110-240 V AC, enabling direct integration into distributed control cabinets without additional supply conditioning.

Signal processing is performed through galvanically referenced analog conditioning stages, enabling format adaptation between voltage-driven and current-loop instrumentation lines. The compact 22.5 mm housing is intended for DIN rail installation in control panels.

Suffix Breakdown & Model Matrix

• Model: CC-E/STD
• Suffix "STD": Standard universal signal converter configuration
• No additional decoding or segmented option matrix is specified in provided data

Hardware Specifications

Backplane Signal Conditioning and Profinet/DCS Interface Adaptation

The CC-E/STD operates as a signal format translation node within industrial control architectures. Within PLC/DCS signal chains, it performs analog domain normalization prior to A/D conversion stages, ensuring voltage-to-current loop compatibility across mixed instrumentation environments.

The module design aligns with DIN-rail mounted I/O interface standards commonly used in modular control cabinets, supporting deterministic signal integrity across varying load impedances. Electrical isolation is implemented at the signal conditioning stage to reduce loop interference and cross-channel coupling in dense cabinet layouts.

Frequently Asked Questions

Q1: Can the CC-E/STD be hot-swapped under energized conditions?
A1: No hot-swap capability is specified. Installation or removal should be performed under de-energized conditions to avoid transient loop disturbances.

Q2: Does the unit support simultaneous V-to-I and I-to-V conversion in separate channels?
A2: The provided specification indicates multifunction operation; however, channel concurrency behavior is not defined in the supplied data and must be verified at configuration level.

Q3: What is the impact on signal accuracy under mixed 0-10 V and 4-20 mA operation?
A3: Accuracy is dependent on load impedance matching and internal scaling configuration. No factory-defined accuracy class is provided in the dataset.

Field Installation Guidelines

• Install on standard DIN rail with secure mechanical locking on both ends of the module
• Maintain separation between high-voltage AC supply wiring and low-level analog signal lines
• Ensure correct polarity alignment for current loop terminals (4-20 mA circuits)
• Use shielded cables for analog signal runs; ground shielding at one control cabinet reference point only
• Verify supply voltage range (110-240 V AC) before energization
• Avoid routing signal cables parallel to high-frequency drive outputs or switching power lines

Other Attributes

• Series:  ABB OCS/800xA

• Country of Origin:  Germany/Finland/Sweden
• Lead Time: In Stock, 2 Working Days
