AEPV7D-111 | Yokogawa | Power Supply Bus Unit
Specifiche tecniche
Manufacturer: YOKOGAWA
Condition：New with Original Package
Product Type: Power Supply Bus Units
-
Country of Origin: Singapore
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Inviando una richiesta per questo articolo, confermi di aver esaminato e accettato i nostri Termini e Condizioni. Si prega di notare che tutte le transazioni saranno elaborate offline.
Chiedi ad un esperto
Aiutaci a raggiungere più persone! Condividi questo prodotto con la tua rete e mostra il tuo sostegno!
Product Description
The Yokogawa AEPV7D-111 is a vertical Power Supply Bus Unit designed for cabinet mounting. It distributes electrical power to connected equipment through a power supply bus. This configuration uses a 100-120 V AC input and supports a maximum bus unit input current of 20 A, with a maximum current of 6 A per port. It is the general cabinet version without explosion protection.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | AEPV7D-111 |
| Brand | Yokogawa |
| Product Type | Power Supply Bus Unit, Vertical Type |
| Input Voltage | 100-120 V AC |
| Input Frequency | 50/60 Hz |
| Withstand Voltage | 1500 V AC |
| Maximum Input Current, Bus Unit | 20 A |
| Maximum Input Current per Port | 6 A |
| Weight | Approx. 2.9 kg |
| Mounting Type | Vertical, cabinet mounting |
| Cabinet Type | General cabinet |
Power Distribution Function
The AEPV7D provides a bus-based power distribution arrangement for equipment installed inside a control cabinet. Its current ratings define the maximum input current for the unit and the maximum current permitted at each port. The connected load and wiring configuration must remain within the applicable ratings.
Ordering Code and Configuration
The AEPV7D series offers different power supply and cabinet configurations. Confirm the complete model code before ordering a replacement.
| Code | Description |
|---|---|
| AEPV7D | Power Supply Bus Unit, Vertical Type |
| -1 | 100-120 V AC power supply |
| -2 | 220-240 V AC power supply |
| -4 | 24 V DC power supply |
| Suffix 0 | For Yokogawa cabinet, for AFV40□/ACB51 |
| Suffix 1 | For general cabinet |
| Suffix 5 | Basic type without explosion protection |
| Suffix 6 | ISA Standard G3 option, without explosion protection |
| Suffix E | Basic type with explosion protection |
| Suffix F | ISA Standard G3 option, with explosion protection |
The AEPV7D-111 specifies a 100-120 V AC supply, general cabinet mounting, and a basic configuration without explosion protection.
Frequently Asked Questions
Q: What input supply does the AEPV7D-111 use?
A: It uses 100-120 V AC at 50/60 Hz. Verify the cabinet supply before installation or replacement.
Q: What are the current limits?
A: The maximum input current for the bus unit is 20 A, and the maximum input current per port is 6 A. Both limits must be considered when checking the connected load.
Q: Is the AEPV7D-111 suitable for explosion-protected installations?
A: No. The specified configuration is the basic type without explosion protection. Other suffix options exist, but their suitability depends on the installation requirements.
Other Attributes
- Country of Origin: Japan/Singapore
- Lead Time: In Stock, 2 Working Days
