BMXNOM0200 Schneider Electric Modicon X80 Serial Link Module

Product Description

The BMXNOM0200 is a serial link module for the Schneider Electric Modicon X80 platform. It provides two serial communication ports for exchanging data with compatible devices using Modbus and character mode. The module supports RS-232 and RS-485 interfaces, allowing different serial communication configurations within an automation system. Rack-based power and individual port activity indicators support system integration and communication status monitoring.

Hardware Specifications

Serial Communication Interfaces

The BMXNOM0200 provides two serial ports with different electrical interfaces and maximum data rates. Port 0 uses RS-232 and supports up to 115.2 kbit/s, while port 1 uses RS-485 and supports up to 57.6 kbit/s. These interfaces allow the module to handle serial data exchange with external equipment, subject to the communication requirements of the connected devices.

The module supports both Modbus and character mode. The appropriate mode depends on the protocol or data format required by the connected equipment. Before commissioning, verify the required communication parameters and the port configuration against the connected device specifications.

Status Indicators and Rack Power

Four LEDs provide local operating and communication status information:

• ERR (red): Indicates a module fault.
• RUN (green): Indicates module operation.
• SER COM 0 (green): Indicates activity on serial port 0.
• SER COM 1 (green): Indicates activity on serial port 1.

The module receives power internally through the rack. Its specified current consumption is 80 mA at 24 V DC. The two serial communication indicators help maintenance personnel identify port activity when checking communication between the controller system and connected devices.

Environmental and Compliance Information

The BMXNOM0200 has a specified operating temperature range of 0 to 60 deg C and a relative humidity range of 10-95% without condensation. Its IP20 rating describes the enclosure protection level; it does not indicate protection against water ingress.

The module carries CE marking and UL 508 certification. Its listed standards include EN 61000-6-2 for electromagnetic immunity, EN 61000-6-4 for electromagnetic emissions, EN 61131-2 for programmable controller equipment, and EN 61010-2-201 for control equipment safety requirements.

The product is identified as a Green Premium product. Environmental documentation, including the product environmental profile and end-of-life instructions, is listed as available.

Frequently Asked Questions

Q: What communication interfaces does the BMXNOM0200 provide?

A: It provides one RS-232 port and one RS-485 port, both using RJ45 connectors. The maximum specified data rates are 115.2 kbit/s for RS-232 and 57.6 kbit/s for RS-485.

Q: Can the BMXNOM0200 communicate using Modbus?

A: Yes. The module supports Modbus and character mode. Confirm that the selected communication mode and port settings match the requirements of the connected equipment.

Q: How is the BMXNOM0200 powered?

A: The module receives its power from the rack's internal power supply. Its specified current consumption is 80 mA at 24 V DC.

Other Attributes

• Series：Modicon Quantum
• Country of Origin:  USA
• Lead Time: In Stock, 2 Working Days
