GE IS200AEADH4A EX2100 Input Terminal Board

Product Description

The General Electric IS200AEADH4A, also identified by the base model IS200AEADH4A, is an input terminal board for alternative energy application D within the EX2100 series. It provides an interface for acquiring analog voltage and current signals through 16 isolated input channels. The specified input ranges include +/-10 VDC, 0-10 VDC, 0-20 mA, and 4-20 mA, with a sampling rate of 10 samples/sec.

Hardware Specifications

Analog Signal Acquisition and Channel Isolation

The IS200AEADH4A accepts analog voltage and current signals within the specified input ranges. Its 16 isolated channels support the separation of input circuits as defined by the board design. The stated sampling rate is 10 samples/sec; the available data does not establish whether this rate applies independently to each channel or to the complete input set.

For installation, verify the input configuration and field wiring requirements against the applicable EX2100 system documentation. Do not assume that all voltage and current ranges are available simultaneously on every channel without confirming the board configuration.

Frequently Asked Questions

Q: Which analog signals does the IS200AEADH4A support?

A: The listed input ranges are +/-10 VDC, 0-10 VDC, 0-20 mA, and 4-20 mA. Confirm the channel configuration before connecting field devices.

Q: What is the sampling rate of the IS200AEADH4A?

A: The specified sampling rate is 10 samples/sec. The available information does not clarify whether this rate is per channel or applies to the complete input set.

Q: What field wiring does this terminal board support?

A: The listed field wiring range is 18-22 AWG. Confirm terminal compatibility and the applicable wiring requirements in the manufacturer's installation documentation.

Field Installation Guidelines

1. Verify the complete part number, IS200AEADH4A, and confirm compatibility with the intended EX2100 system configuration.
2. Isolate the relevant power sources and follow the site's electrical safety and lockout procedures before wiring.
3. Identify each field signal and verify its voltage or current range before connecting it to the assigned input channel.
4. Use field conductors within the specified 18-22 AWG range, subject to terminal and installation requirements.
5. Route analog signal wiring separately from high-current power conductors and sources of electrical interference where practical.
6. Apply cable shielding and grounding according to the manufacturer's instructions and the site's grounding design. Avoid unintended ground loops.
7. Inspect terminal connections for correct polarity, secure termination, and conductor clearance before energizing the system.
8. Verify channel readings and system diagnostics during commissioning. Consult the applicable GE documentation for isolation limits, input protection, power requirements, and configuration procedures.
