Bently Nevada 114M5335-01 Low Voltage DC Power Input Module

Product Description

The Bently Nevada 114M5335-01, also cataloged as the 114M5335 Low Voltage DC PIM, operates as a dedicated hardware component for direct physical/electrical execution of low voltage DC power interfacing within 3500 Series Machinery Protection System racks.

Hardware Specifications

Eddy-Current Probe Scaling and Gap Voltage Validation

When integrated into the 3500 rack, the 114M5335-01 supports eddy-current probe scaling operations by delivering stable low voltage DC power to associated monitoring modules. This stability directly affects gap voltage validation, where -10 VDC targets represent standard quiescent bias levels for proximity transducer systems. Furthermore, the module's noise suppression characteristics contribute to cross-talk suppression across adjacent transducer channels, preserving rotor dynamics measurement fidelity in turbomachinery applications.

Frequently Asked Questions

Q: Does the 114M5335-01 support hot-swap insertion while the 3500 rack remains energized?

A: No. The module must be installed or removed only after the associated low voltage DC power supply (114M5330-01) is de-energized. The fuse protection circuit does not provide in-service insertion capability.

Q: What is the backplane current load imposed by this PIM on the 3500 rack?

A: When paired with the 114M5330-01 Low Voltage DC Power Supply, the combined maximum rack current draw is 11.0 A. Individual PIM current consumption is governed by the connected supply module's output rating.

Q: How does the module respond to input voltage dropping below 20 VDC?

A: Under-voltage conditions do not damage the PIM or the associated power supply. The module simply ceases to deliver specified output until input voltage returns to the 20-30 VDC operating range.

Field Installation Guidelines

Install the 114M5335-01 in the designated left-side slot of the 3500 rack, directly behind the 114M5330-01 Low Voltage DC Power Supply. Use the provided screw terminals to secure incoming DC power conductors. Torque terminal screws to the manufacturer's specified values to prevent thermal rise. Route power wiring separately from transducer signal cables to minimize inductive coupling. Ensure the rack ground bus is bonded to plant earth ground before applying power. Verify input voltage polarity prior to energization; reverse polarity may cause fuse operation.
